High Performance PTFE Laminated Membrane

PTFE (fine powder resin) is expanded into a 3-dimensional web-like structure called ePTFE membrane which creates billions of microscopic pores.
This structure utilizes the inherent hydrophobic (water-resistant) and non-stick nature of PTFE to allow removal of particulate captured on the membrane surface.
The filter level is from F9-U15, which meets the international requirements such as EN1822, EN779 etc.

Send Inquiry

Product Introduction

Advantages of ePTFE Membrane Products

1. Hydrophobic

The hydrophobic nature of PTFE promised its long-lasting unwetted status even be kept contacting with water or other normal liquids, and the open porous structure provides a wide range of pore size, 0.02um tp 10 um, ensuring the retention of bacteria, virus and particles is always effective while maintaining the excellent air permeability.

2. Low Resistance

The filtration efficiency reaches 99.9995% with high filtration efficiency, can meet the filtration efficiency level requirements of sub-efficient, efficient and ultra-efficiency air filter, better than other filtration materials

3. High Air permeability

Ultra-thin PTFE film can be made air permeable by controlled stretching. This process creates millions of micropores per sq cm offering a high air permeability.

Normally, high air permeability is considered to be related to lower dust collection efficiency. However, the micropore diameter in PTFE stretched film ranges from 0.1 µm to 10 µm. This is wide enough for air to pass freely but offers excellent dust particle collection.

Specification

Efficiency Class	Basic Weight	Resistance @5.3cm/s	Efficiency @0.1-0.2um
E12	60g~240g	Max.120Pa	Min. 99.5%
H13	60g~240g	Max. 140Pa	Min. 99.97%
H14	60g~220g	Max. 220Pa	Min. 99.995%
U15	60g~150g	Max. 320Pa	Min. 99.9995%
Remark: Customized requirements acceptable. Support Type: Polyester, Bi-component polyester, heat-bonding lamination, glue-bonding lamination, etc.

Application

This product is widely used in air purification and filtration (vacuum cleaner filters, clean room filtration, personal protection, etc.) and industrial dust removal (filter cartridges etc.) and other industry fields.

1. The combination of water resistance, air permeability, and particle retention introduces ePTFE membrane products into various medical applications involving long-lasting liquid resistance and air venting / gas filtration.

2. In industrial areas, laminated PTFE membrane are widely used as cleanrooms, HVACs, dust collection in kinds of air filters, cartridge filters etc.

3. The high efficiency of PTFE-based filters has opened the door to other markets such as consumer electronics and personal protection equipment. Vacuum cleaners have become more powerful over the past decade.

Multiple Structures

JM PTFE membrane is compatible with multiple sealing methods, ultrasonic, heat, radio frequency welding, mechanical, and inserting molding, offering our clients more possibilities of sealing solutions, given the quality is as marvelous as promised.
