Meltblown 20 Gsm Non-woven Fabric
JM melt-blown nonwovens are made in China beneath special best requirements with approved third-party certificates.
Product Properties
● Self-bonding
● Large area / weight ratio
● Adjustable structure of pores and capillaries
● Hydrophobic / Oleophilic
● High filtration efficiency
● Electrostatically charged
● Optional additives
Production Process
Through a nozzle made of a row of several hundred pinholes, the plastic melt is spun out. The nozzle tip emits hot air on both sides, which causes the polymer streams to condense into very tiny filaments. High-speed hot air is used to pull these filaments onto a filter belt. The end result is a melt-blown fleece with exceptional filtration and barrier capabilities.
Specification
Technical Performance | |||
Raw materials | 100% polypropylene | Grammage | 20g or 25g/㎡ |
Fiber diameter | 1-5 microns | Porosity | ≥75% |
Nonwoven technics | Melt blowing | Width | 175mm/195mm/customized |
Item | Basic Weight | Efficiency | Pressure Drop | Test Methods |
JM020K9000N | 20g±3g | Min. 90% | Max. 25Pa | Test method: TSI 8130 |
JM020K9500N | 20g±3g | Min. 95% | Max. 30Pa | |
JM020K9700N | 20g±3g | Min. 97% | Max. 35Pa | |
Remark: Customized Specs acceptable. | ||||
Application
● Face masks/ respirators material
Mask filter material, there are medical and labor insurance two series of products.
Medical mask material can meet the European standard EN14683, bacterial filtration efficiency (BFE) above 99%, particle filtration efficiency (PFE) above 99%, virus filtration efficiency (VFE) above 99%.
The filter material of labor protection mask can meet European standard EN149, American standard NIOSH42 CFR-84, Japanese MOL standard and Chinese standard GB 2626 dust mask.
And it can be made into European standard FFP1, FFP2, FFP3, American standard N95, N99, N100, R95, R99, Japanese standard DS1, DS2, Korean standard KF94, National standard KN90, KN95, KN100, KP90, KP95, KP100 and other levels of protective dust mask and equipment.
● Others
Air filter material:
It can be used to create mini-pleated filters, panel filters, and pocket filters that comply with EN779, EN1822, and ISO 16890 and are widely used in vehicle air conditioning systems, central air conditioning systems, cleaning room purification fields, and other medium high effectiveness filtration systems.
Hygiene material & wipes
Pictures
Packing & Storage
Packing: Our soften blown non-woven material will be packed in rolls and covered thru potential of stretch films, and stick labels with all the required information consisting of weight, width, object number, etc.
Storage: The product ought to be positioned in the ventilated dry place the region is now no longer straight ahead to insolate.
Do OEM purchases have any special requirements?
A. Prior to printing or embossing your trademark on a product or packaging, we must have proof that it has been registered.
What distinguishes you from your competitors?
(1). Reputable manufacturer (2). Genuine Quality Assurance (3). Reasonable Cost (4). High production (round-the-clock) (5). a single location
Do technical specifications and drawings exist?
A: Our highly skilled technical team will produce and provide technical data and drawings.
Have any of your products been exported?
The USA, Canada, Australia, Russia, Chile, Panama, Nicaragua, United Arab Emirates, Saudi Arabia, Egypt, Sri Lanka, Nigeria, Iran, and Vietnam are just a few of the nations that have received them.
